PU7052 Two Component Polyurethane Structural Adhesive
Product Highlights
- High strength
- Aging resistance
- Vibration fatigue resistance
- Low temperature corrosion resistance
- Low odor, low emissions
- Excellent flame retardant performance
- Suitable for bonding multiple materials
Product Applications
- adhesive between cells in batteries
- Adhesive bonding between two structural modules
- Adhesive and sealant for components
SPECIFICATIONS TABLE PU7052
| Item | Unit | Index | Typical Value | Test Method |
| appearance | / | A: Black paste B: White paste | A: Black paste B: White paste | visual |
| density | g/cm3 | A: 1.40 ± 0.05 B: 1.40 ± 0.05 | A: 1.37 B: 1.39 | GB/T 533-2008 |
| Viscosity | cps | A: 150,000~200,000 B: 150,000~200,000 | A: 170,000 B: 160,000 | GB/T 2794-2013 10 rpm |
| Mixing ratio | v/v | 1:01 | 1:01 | / |
| surface drying time | min | 15–20 | 16 | GB/T 13477.5-2002 |
| hardness | Shore D | 65 ± 5 | 65 | GB/T 531.1-2008 |
| Body tensile strength | MPa | ≥ 8.0 | 10 | GB/T 528-2009 |
| elongation at break | % | ≥ 40 | 70 | GB/T 528-2009 |
| tensile shear strength | MPa | ≥ 15.0 (Al–Al) | 15.7 | GB/T 7124-2008 |
| pull strength | MPa | ≥ 11.5 (Al–Al) | 17 | GB/T 6329-1996 |
Operation and Safety Guidelines
Surface Preparation:
Before applying the adhesive, clean the surface using gauze or appropriate tools to remove dust, loose particles, oil stains, and water marks. If rust is present, remove it with a wire brush, then clean the area using acetone or alcohol.
Primer and Cleaning Agent:
To ensure optimal adhesion, use the appropriate primers and cleaning agents. When applying these materials, make sure the coating is uniform, with no excess buildup or missed areas on the substrate surface.
Mixing:
PU7052, a two-component polyurethane structural adhesive, should be mixed using a static mixing tube.
Application:
Apply the PU7052 adhesive using a pneumatic or electric dispensing gun, or other suitable application equipment, directly at the construction site.
Packaging, storage, and expiration date
We can provide 50 mL, 400 mL, and 600 mL two-component rubber hose packaging or 20 L small buckets and 200 L large buckets packaging according to customer requirements;
It is recommended to store in a cool and dry place for a storage period of 6 months;
Incorrect storage conditions can affect product application and performance after curing.
Packaging, Storage, and Shelf Life
We offer packaging options including 50 mL, 400 mL, and 600 mL two-component cartridges, as well as 20 L pails and 200 L drums, depending on customer requirements.
For best results, store the product in a cool, dry environment. The recommended shelf life is 6 months.
Improper storage conditions may impact the product’s application performance and cured properties.
